1) Monday through Thursday depress MO followed by TH.
2) Wednesday through Sunday depress WE followed SU.
2. Daylight Savings Programming
The cursor will appear under DS (auto clock adjust daylight savings mode) in display. To
change mode depress
UP or DWN once ST (clock does not adjust standard time mode)
will appear in display. Depress ENTER to accept correct selection.
Note: Select DS for areas that observe daylight savings or ST for areas that don’t
observe daylight savings.
D. Setting Holiday Events: (These events will occur on programmed Holiday Dates - see
Setting Holiday Dates below).
Select channel A or B by moving slide switch SW3 to appropriate position.
Note: Channel cannot be changed in the middle of programming events. To change channels
you must exit programming then change channel switch position then enter program mode again.
Find the first unprogrammed event (refer to Adding Events - section B2 page 6).
Depress
ENTER until the flashing cursor appears under OFF (relay function) position in
display. Now select type of operation required, by scrolling using the UP and DWN push
buttons until either:
ON - Relay ON (latching mode).
OFF - Relay OFF (latching mode).
PL - Relay Pulse ( momentary).
appears in display and depressing
ENTER will make selection.
When selecting the pulse mode PL01 will appear in the display. It is now necessary to assign
the length of time (duration of relay activation). The pulse can range in length from 1 second
minimum to 15 seconds maximum and is selected by using
UP or DWN push buttons,
then depressing ENTER to accept.
Note: If pulse duration is not selected relay output defaults to 1 second.
Next select
HL (holiday) and time (military) by scrolling using UP and DWN push buttons
and depress ENTER to accept. You may continue to program events by repeating the previous
steps or exit programming by depressing SET.
E. Setting Holiday Dates:
Select channel A or B by moving slide switch SW3 to appropriate position.
Note: Channel cannot be changed in the middle of programming events. To change channels
you must exit programming then change channel switch position then enter program mode again.
It is now necessary to assign these holiday events specific calendar dates which they
are to occur.
Depress SET until ENTER to
SET HOL
Depress ENTER A01 HOL
SU 00:00
- 6 -
appears in display.
will appear in display.
>
