Maximal11/Maximal33/Maximal55/Maximal77/Maximal75 Access Power Controllers (Fused) - 3 -
Maximal Series Overview:
Maximal Access Power/Controllers distribute and switch power to access control systems and accessories. They convert a
115VAC 60Hz input into sixteen (16) independently controlled 12VDC or 24VDC fuse protected outputs. These Fail-Safe/
Fail-Secure power outputs may be converted to dry form “C” contacts. The outputs are activated by an open collector sink
or normally open (NO) dry trigger input from an Access Control System, Keypad, Push Button, REX PIR, etc. Units will
route power to a variety of access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door Holders,
etc. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices.
The fire alarm disconnect feature is individually selectable for any or all of the sixteen (16) outputs. All interconnecting
equipment must be UL Listed.
Maximal Series Configuration Chart:
Altronix
Model
Number
Output Voltage Options
Total Output Current (16 outputs) Fuse Protected Outputs 115VAC 60 Hz Input (current) Power Supply Board Input Fuse Rating Power Supply Board Output Fuse Rating Agency Listings and File Numbers Power Supply 1 Power Supply 2
Maximal11
AL400ULXB AL400ULXB
16* 7A 5A/250V 15A/32V
California State
Fire Marshal Approved
UL File # BP6714
UL 294
UL Listed for
Access Control
System Units.
12VDC @ 3.5A 12VDC @ 3.5A 7A
12VDC @ 2.7A 24VDC @ 2.7A
5.4A
24VDC @ 3.5A 24VDC @ 2.7A
6.2A
Maximal33
AL600ULXB AL600ULXB
16 7A 5A/250V ---
12VDC @ 5.5A 12VDC @ 5.5A 11A
12VDC @ 5.7A 24VDC @ 5.7A 11.4A
24VDC @ 5.5A 24VDC @ 5.7A 11.2A
Maximal55
AL1012ULXB AL1012ULXB
19 16 5.2A 5A/250V 15A/32V
12VDC @ 9.5A 12VDC @ 9.5A
Maximal75
AL1012ULXB AL1024ULXB
19.2 16 6.8A
5A/250V
(AL1012ULXB)
and
1024ULXB)
15A/32V
(AL1012ULXB)
and
1024ULXB)
12VDC @ 9.5A 24VDC @ 9.5A
Maximal77
AL1024ULXB AL1024ULXB
19.4 16 8.4A 5A/250V 15A/32V
24VDC @ 9.7A 24VDC @ 9.7A
*Maximal11 outputs are power-limited.
Maximal Series Features:
• Sixteen (16) independently trigger controlled outputs.
Output options:
a) Sixteen (16) Fail-Safe filtered and electronically regulated power outputs.
b) Sixteen (16) Fail-Secure filtered and electronically regulated power outputs.
c) Sixteen (16) form “C” relay outputs (rated @ 5 amp/28VDC or VAC).
d) Any combination of the above.
• Sixteen (16) Access Control System trigger inputs.
Input trigger options:
a) Sixteen (16) normally open (NO) dry trigger inputs.
b) Sixteen (16) open collector inputs.
c) Any combination of the above.
• Sixteen (16) unswitched filtered and electronically regulated aux. power outputs (outputs are rated @ 2.5 amp).
• ACM8 maximum current is 2.5 amp per output.
• Red LEDs on ACM8 board indicate individual outputs are triggered (relays energized).
• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the sixteen (16) outputs.
