VEGACOM 557 VEGA ASCII
Switch position on VEGACOM 557 additional print
Setup
DIL switch block 3
(additional board)
Bus address
of VEGACOM 557 = 1
(Adr. 1 to 9)
free
DIL switch block 1
(additional board)
Selection of the interface type
Bus termination for RS 485/
422
Protocol selection
RS 232
without meaning
VEGA ASCII
DIL switch block 2
(additional board)
Protocol mode
high resolution
DCS measured value image
(only relevant on VEGAMET)
1. meas. value Met 1,
1. meas. value Met 2,
etc.
Parity
none
Number of data bits
8
Selection of the baud rate
9600
VEGA ASCII with
RS 232
9600,8,N,1
high resolution
VEGACOM 557 address
= 1
1
2
3
4
5
6
7
8
ON
1
2
3
4
5
6
7
8
ON
1
2
3
4
5
6
7
8
ON
