Figure 20
Step 4:
Remove the two temperature bolts on the right side using a 3/8” socket wrench. The
temperature module should be free now. Remove and place to the side.
Step 5:
Remove the two shank bolts on the right side, the shank should now be free.
Figure 21
Temperature
module bolts
Shank bolts
Complete shank module
after removal
