Construction







C12 : 100nF / 250Vac

12. Capacitor.





SK4 : 3p

DMX input

13. Board to wire connector





X1

: 20MHz

14. Quartz crystal

X...







SK1 : 2p

AC input



SK2 : 2p

Lamp output

16. Terminal blocks







F1 : 5A

(slow)



F2 : 100mA

(fast)

17. Fuses

F...





C10 : 220µF/25V



C11 : 220µF/25V

15. Electrolytic capacitors
Watch the polarity!

C...











VR1 : UA7805

18. Voltage regulator

VR...
