3

Features & specifications

This kit allows you to control a lamp or group of lamps through a DMX signal. The DMX protocol was devel-
oped by USITT in 1986 with the purpose of controlling dimmers, scanners, moving heads and other lighting
devices with simple wiring. It is mainly being used in theatres and discos, but you can use it in any place
where a central or automated lighting is needed.

Use our “USB controlled DMX interface” K8062 (kit version), VM116 (assembled version) or any other control
console compliant with the DMX-512 protocol as a controller

FEATURES:



suitable for resistive loads like incandescent lamps and mains voltage halogen lighting



system addressability: 512 unique addresses, selectable with DIP switch



status LED for power and error detection



toroidal filtering for low noise (according to EN55015)



stand alone “test” mode



control source: DMX-512, 3 pin XLR socket included


SPECIFICATIONS:



load capacity: max. 1000 W @ 230V (5A) or 500W @ 115V



power Input: 115/230 VAC



size: 150 x 60 x 45mm / 5,9 x 2,36 x 1,77"

modifications reserved
