March 2009
RFID Proximity Card Reader MK179
Technical:
RFID: 125kHz EM4100 compatible
Relay output: 3A / 24V max.
Power supply: 12VDC / 100mA
Dimensions: 66x62x20mm
Extra badge: HAA86C/TAG2
Extra card: HAA86C/TAG
Detection distance: up to 10cm
Options:
RFID
64 bit
3A
25
Applications: Open doors, fences, gates, etc...
Arm/disarm security systems in homes / offices / vehicles etc...
Prevent unauthorised use of equipment, machinery, computer systems
etc... Automate cat doors...
0.5s-4min
RFID technology
Store up to 25 tags
Excellent security: 64-bit coded
Unlimited # of tags in
low-security mode
Two tags supplied (card-type)
Easy addition and removal of
tags
Output activation: 0.5s to 4min
or toggle (ON/OFF)
Coil can be mounted away from
the board (up to 5m) for higher
security
2 pcs included
