October 2008 October 2008
LED Dimmer with RF remote control VM152
Technical:
Power supply: 12-24VDC
Max load: 6A
LED PWM freq: +/- 300Hz
On-board operation is possible
Dimensions: approx 80x70x23mm
Remote:
433.92 MHz operation
R&TTE compliant ( ETS 300-220)
Bat: 12V (GP23GA/V23GA) incl.
Dim: 63 x 40 x 16mm (2.5" x 1.6" x 0.6")
UP
DOWN
6A
Hi power MOSFET output
Memory for last selected function
Also suited for incandescent
lamps
DOWN UP
12-24VDC
IN
OUT
6A max.
LED indicator
Learn up to 16 remotes
Ideal for use with LED strips
See:
http://www.velleman.be/be/en/
product/list/?id=373414
Automated Slow on / slow off effect
mode selectable
Option:
Extra remote: VM130T
PWM
NO
T F
OR
U.S
.
