Connector chart, Appendix – Spicer TIMS (Tire Inflation and Monitor System) for Trailers Installation Guide User Manual
Page 38
35
Appendix
Connector Chart
Component
Harness Connector
Shell
Harness Terminal
Wire Seal
Lock
Plug
Warning Lamp
Female
Bullet Connector
To SAE J560
To ABS
Service Tool
Data Link
Deutsch
Deutsch
Deutsch
114017
HD10-6-12P-L
Manifold
Pressure Sensor
Packard
12103881
Secondary Lock
Packard
12052845
Packard
12110293
Packard
12065287
Electronic Control Unit
Deutsch
Socket
Deutsch
Deutsch
DTM06-12SA Deutsch
WM-12S
0413-204-2005
1062-20-0122
__
__
__
__
__
218UX020
Packard
12048074
Manifold Solenoids
0460-204-12141
__
__
__
__
__
__
__
__
__
__
__
__
__
__
__
__
__
