Spicer TIMS (Tire Inflation and Monitor System) for Trailers Installation Guide User Manual
Page 28
25
Installation
Configuration, Clocking, and Tire Hose Selection Chart
2-Hole or 4/6 Spoked
Wheel Installation
(any size wheel)
Clock "C"
5-Hole or 5-Spoked
Wheel Installation
(17.5" or 22.5" Wheel)
Clock "A"
5-Hole or 5-Spoked
Wheel Installation
(19.5" or 24.5" Wheel)
Clock "B"
Wheel Size
Hole Config
Hose – Inner
Hose – Outer
Clock
2
5
676481
676388
676482
676387
17.5 X
X
X
C
17.5
X
X
X
A
19.5 X
X
X
C
19.5
X
X
X
B
22.5 X
X
X C
22.5
X
X
X A
24.5 X
X
X C
24.5
X
X
X B
Single n/a
n/a
n/a
n/a
n/a n/a
X
