Driveshaft, Outboard slip coupling shaft, Spicer life – Spicer Axle, Driveshaft, Tire Management Systems, and Wheel-End Systems Specifications Guide 2013 User Manual
Page 29: Series – medium-duty
This guide is periodically updated throughout the year. The most current information can be found on www.dana.com/cv
27
A
E
S
B
C
F
G
Outboard Slip Coupling Shaft
For additional configurations, contact Spicer Driveshaft Engineering for specific application information.
Driveshaft
Spicer Life
®
Series – Medium-Duty
Driveshaft
Assembly
Part
Number
Minimum Length
Collapsed
Centerline to
Centerline of
Cross
"A"
Slip Joint End
Tight Joint End
U-Joint
Span
"F"
Bearing
Cup Diameter
"G"
Slip
"S"
Max.
Angle
"B"
Centerline of
Bearing to
Centerline of
Slip Yoke
Collapsed
"E"
Tube Size
Max.
Angle
"C"
MM
IN
MM
IN
MM
IN
MM
IN
MM
IN
MM
IN
SPL-55
055CS55003
375
14.77
110
4.33
27°
254
9.84
88.9 x 2.11 3.50 x .083 21.5°
106
4.19
35
1.37
SPL-55XS
055CS55003G
SPL-70
070CS55003
390
15.34
110
4.33
25°
260
10.25
88.9 x 2.41 3.50 x .095
26°
126
4.96
35
1.37
SPL-70XS
070CS55003G
SPL-100
100CS55002
449
17.66
110
4.33
25°
273
10.75 101.6 x 2.41 4.00 x .095
25°
126
4.96
41
1.63
SPL-100XS
100CS55002G
