Single Reduction Single Drive Axles
Axle
Model
Ratings
Ratios
Axle Shaft
Ring
Gear
Dia. in.
Axle Housing
Weight
lbs. [kg]
(Nominal)
Spindle
Type
Options
Max. GAW
lbs. [kg]
Max. GCW
lbs. HWY
[kg]
Body Diameter
in. [mm]
Number of
Splines
Spline Diameter
in. [mm]
Box Section
Width
Box Section
Height
W
all thickness
at spring seat
LMS™ Hub Central T
ire
Inflation System
(CTIS)
Differential Lock
Parking Brake
Limited Slip
No Spin
S14-110  14,000
[6,364]
35,000
[15,876] 3.73, 3.91, 4.10, 4.30,
4.56, 4.78, 4.88, 5.13,
5.38, 5.57, 5.86, 6.14,
6.50
1.57
[40]
34
1.75
[44]
11.8
[300]
4.25
[108]
4.25
[108]
0.31
[8]
345 [156]
Varies by
OEM S16-130  16,000
[7,273]
40,000
[18,144]
1.61
[41]
36
1.89
[47]
12.2
[310]
0.39
[10]
367 [167]
S17-140* 17,000
[7,711]
50,000
[22,680]
3.31, 3.58, 3.73, 3.91,
4.10, 4.30, 4.56, 4.88,
5.29, 5.57, 6.14, 6.50
1.81
[46]
39
2.00
[51]
13.4
[340]
4.61
[117]
5.24
[133]
0.39
[10]
433 [196] L
S19-140* 19,000
[8,618]
50,000
[22,680]
3.31, 3.58, 3.73, 3.91,
4.10, 4.30, 4.56, 4.88,
5.29, 5.57, 6.14, 6.50
1.81
[46]
39
2.00
[51]
13.4
[340]
4.61
[117]
5.24
[133]
0.39
[10]
433 [196] L
17060S  17,000
[7,711]
60,000
[27,216]
3.08, 3.25, 3.36, 3.55,
3.70, 3.90, 4.11, 4.30,
4.33, 4.63, 4.78, 4.88,
5.29, 5.57, 6.17, 6.50,
7.17
1.81
[46]
39
2.00
[51]
15.4
[391]
4.61
[117]
5.24
[133]
0.37
[9]
519 [235]
L
19060S  19,000
[8,618]
21060S  21,000
[9,525] 1.89
[48]
41
2.10
[53]
R
22060S  22,000
[9,979]
0.43
[11]
562 [255]
BLUE AREAS INDICATE AVAILABILITY.
Spicer Two-Speed and Planetary Double Reduction Single Drive Axles
Axle
Model
Ratings Ratios Axle Shaft
Ring Gear
Dia. in.
Axle Housing
Weight
lbs. [kg]
(Nominal)
Spindle
Type
Options
Max. GAW
lbs. [kg]
Max. GCW
lbs. HWY
[kg]
Two Speed
Double
Reduction
Body Diameter
in. [mm]
Number of
Splines
Spline Diameter
in. [mm]
Box Section
Width
Box Section
Height
W
all thickness
at spring seat
LMS™ Hub Central T
ire
Inflation
System (CTIS)
No Spin
19055T
19055P
19,000
[8,618]
60,000
[27,216]
3.90/5.32, 4.11/5.61,
4.33/5.91, 4.63/6.31,
4.88/6.65, 5.29/7.21,
5.57/7.60, 6.17/8.42,
6.50/8.87, 7.17/9.77
5.32, 5.61,
5.91, 6.31,
6.65, 7.21,
7.60, 8.42,
8.87, 9.77
1.81
[46]
39
2.00
[51]
See Note
4.61
[117]
5.24
[133]
0.37
[9]
605 [274]
L
21065T
21065P
21,000
[9,525]
1.89
[48]
41
2.10
[53]
R
22065T
22065P
22,000
[9,979]
0.43
[11]
634 [288]
Spicer Single Reduction Tandem Drive Axles
Axle
Model
Ratings
Ratios
Axle Shaft
Ring
Gear
Dia.
in.
Axle Housing
Weight
lbs. [kg]
(Nominal)
Spindle
Type
Options
Max. GAW
lbs. [kg]
Max. GCW
lbs. HWY
[kg]
Body Diameter
in. [mm]
Number of
Splines
Spline Diameter
in. [mm]
Box Section
Width
Box Section
Height
W
all thickness
at spring seat
Limited Slip
No-Spin
Differential
DS344 34,000
[15,422]
90,000
[40,823]
3.36, 3.55,
3.70, 3.90,
4.11, 4.33,
4.63, 4.88,
5.29, 5.57,
6.17, 6.50
1.81
[46]
39
2.00
[51]
15.4
[391]
4.61
[117]
5.24
[133]
0.37
[9]
1202 [545] L
Rating is subject to Dana engineering application approval.  Optional GenTech TM gearing for coach and bus applications available in this model. * GenTech TM gearing is standard for this model.
Rating is subject to Dana engineering application approval. Note: 16" [406mm] diameter ring gear for 3.55/4.83 and 3.70/5.05 ratios only. Ring gear diameter is 16.5" [419mm] for all other ratios.
Rating is subject to Dana engineering application approval.
Drive Axle
Medium-Duty Drive Axle
