This guide is periodically updated throughout the year. The most current information can be found on www.dana.com/cv
20
Spicer Life
®
Series Operating Parameters
Tubing sizes for Spicer Life
®
Series
Journal Cross and Bearing Kits
SF = Service Free
Driveshaft
High Torque, Low RPM Applications
Handling heavy loads over the long haul has never been easier or more efficient, thanks to Dana’s Spicer Life
®
Series driveshafts. Now enhanced to offer even greater torque, durability, and savings, SPL
®
products offer 70 percent
more power density than their nearest competitor and a 40 percent increase in bearing life. No other U-joint meets the
needs of high-efficiency truck applications better than the SPL U-joint. This product is now available with a service-free
option for even greater savings.
Series
Max. momentary
joint angle
Standard slip
Rotating Diameter
of Shaft
Rotating
Diameter of End Yoke
SPL-140
25°
110 mm
4.33 in
160 mm
6.30 in
174 mm
6.22 in
SPL-170
25°
110 mm
4.33 in
185 mm
7.28 in
193 mm
7.60 in
SPL-170I/A
45°
150 mm
5.90 in
185 mm
7.28 in
193 mm
7.60 in
SPL-250
25°
110 mm
4.33 in
185 mm
7.28 in
193 mm
7.60 in
SPL-250HD
25°
110 mm
4.33 in
185 mm
7.28 in
193 mm
7.60 in
SPL-250 I/A
45°
150 mm
5.90 in
185 mm
7.28 in
193 mm
7.60 in
SPL-350
15°
110 mm
4.33 in
206 mm
8.11 in
219 mm
8.62 in
SPL-350HD
15°
110 mm
4.33 in
206 mm
8.11 in
219 mm
8.62 in
Series
Tubing OD
Wall thickness
SPL-140
107 mm
4.21 in
3.5 mm
.138 in
SPL-140HD
110 mm
4.33 in
5 mm
.197 in
SPL-170
126 mm
4.96 in
3 mm
.118 in
SPL-170HD
128.5 mm
5.06 in
4.25 mm
.167 in
SPL-170I/A
116.7 mm
4.59 in
4.57 mm
.180 in
SPL-250
128.5 mm
5.06 in
4.25 mm
.167 in
SPL-250HD
130 mm
5.12 in
5 mm
.197 in
SPL-350
138.5 mm
5.45 in
4.25 mm
.167 in
SPL 350HD
140 mm
5.51 in
5 mm
.197 in
Series
U-Joint Kit for Quick Disconnect™ End Yoke
SPL-140
SPL-140X
SPL-170
SPL-170-4X
SPL-170SF
SPL-170-SF4X
SPL-250
SPL-250-3X
SPL-250SF
SPL-250-SF3X
SPL-350
SPL-350X
SPL-350SF
SPL-350SFX
