This guide is periodically updated throughout the year. The most current information can be found on www.dana.com/cv
21
Diamond Series
™
Driveshafts
Driveshaft
Spicer Life
®
Series – Heavy-Duty
Driveshaft
Assembly
Part
Number
Minimum Length
Collapsed
Centerline to
Centerline of
Cross
"A"
Slip Joint End
Tight Joint End
U-Joint
SPAN
"F"
Bearing
Cup Diameter
"G"
Slip
"S"
Maximum
Angle
"B"
Tube Size
Maximum
Angle
"C"
MM
IN
MM
IN
MM
IN
MM
IN
MM
IN
250DS55031C
250DS55031F
1981.9
78.0
110
4.33
25°
178.8 x 6.75 DOM 7.0 x .265 DOM
25°
163
6.42
60
2.37
250DS55032C
250DS55032F
2632.9
103.7
110
4.33
25°
215.9 x 6.75 DOM 8.5 x .265 DOM
25°
163
6.42
60
2.37
For additional configurations, contact Spicer Driveshaft Engineering for specific application information.
A
S
B
C
A
B
S
C
( 1697.3 )
