6.4 Waveforms
When a measurement is running these waveforms can display either the live signal or the selected
event in the event table. This display mode is selected using the
button at the right side of
the main interface.
Acoustic Channel
This indicator displays either the
Time Signal (RTA) or the SPL
levels.
Vibration X Axis
Vibration Y Axis
Vibration Z Axis
These indicators display the
vibration time signal.
To change the displayed event, click on the Event table on the desired event.
