Shogun Motorsports Yamaha YZFR6S (06-09) DMP Fender Eliminator Instructions - Manual

Moto 911 Inc. – 1062 Calle Negocio, Ste. J, San Clemente, Ca. 92673 – (949)453-9111
Kit Contents
Part Number Description Quantity
99-FE-670-6300 Fender Bracket 1
99-Wash6x15 6x15mm Washer 8
99-LN-6 6mm Lock Nuts 8
99-HB-6x20 6x20 Bolt 4
99-HB-6x12 6x12 Bolt 4
99-Wash6x12 6x12mm Washer 4
1 - Remove rear Seat.
2 - Disconnect (2) wires from the marker lights and (1) wire from the License Plate light.
3 – Remove (4) stock fender bolts. Remove fender by gently pulling wires and fender down towards
tire. (Fig.1)
4 – Mount “DMP Fender Eliminator Kit” by using the provided 6MM bolts with supplied washers and
lock nuts. Torque bolts as necessary.
5 - Connect License Plate light and marker lights (not included), then check for proper function.
6 – Re-install Rear Seat.
7- Remaining hardware to be used for mounting license plate.
Note: To complete your installation we recommend using DMP Marker Lights and DMP OEM Type
Wire Harness, which are available from your local DMP dealer or www.moto911.com.
Use blue thread locker to secure bolts. Refer to owner’s manual for proper torques.
Yamaha R6 03-05
Yamaha R6S 06-09
Fender Eliminator Kit
P/N: 670-6300
Fig 1
