Shogun Motorsports For motorcycles

Ducati 848/1098/1198 (ALL) NO CUT Under Body
Frame Slider Installation Instructions
Part Number: 750-8309
MADE IN THE USA!
Carefully read instructions in their entirety before the install
Professional installation is recommended. Always use proper safety measures during the install of this
product. Do not try to install this product without proper tools, recently calibrated torque wrench,
correct torque specifications from
factory service manual
, safety goggles and gloves. The motorcycle
must be in a fixed secure position before the install process begins. Safely support engine when
removing the stock though engine stud.
Shogun is not responsible for any part of your motorcycle for
any reason.
Precisely measure location of cut and if in doubt at any point please call us before the install
process has begun. Some photos in this section are used for
illustration
examples only.
Replacement Parts List: Left Side Components (as if you were sitting on the bike)
QTY
Price each
Part Numbers
Descriptions
1
$25.00
99-FS-750-8309-L
Black Left Side Puck
1
$25.00
99-HR-TH121250428
Socket Cap 12 X 1.25 X 428 Main Engine Through Stud
1
$0.50
99-HN-LN12125
12 x 1.25 Hex Flange Lock Nut
1
$15.00
428-9098
Left and Right Side Bell Type Spacer
Replacement Parts List: Right Side Components (as if you were sitting on the bike)
1
$25.00
99-FS-750-8309-R
Black Right Side Puck
1
$0.50
99-HN-LN12125
12 x 1.25 Hex Flange Lock Nut
1
$15.00
428-9098
Right Side Bell Type Spacer
Frame Sliders: Left and Right hand frame sliders are the same. Left and Right hand spacers are the same
1.
Make sure the vehicle is in a fixed secure position. Remove upper fairings.
