Shogun Motorsports Kawasaki ZX10R (04-05) Frame Slider User Manual
Shogun Motorsports For motorcycles

Kawasaki ZX10R 04-05 Frame Slider Installation
Instructions
Part Numbers: 750-4909, 755-4909, 750-4900,
850-4900
MADE IN THE USA!
Carefully read instructions in their entirety before the install
Professional installation is recommended. Always use proper safety measures during the install of this
product. Do not try to install this product without proper tools, recently calibrated torque wrench,
correct torque specifications from
factory service manual
, safety goggles and gloves. The motorcycle
must be in a fixed secure position before the install process begins. DO NOT remove both engine studs
at the same time.
Shogun is not responsible for any part of your motorcycle for any reason.
If you have
any questions please call us directly for assistance.
Replacement Parts List: Left Side Components (as if you were sitting on the bike)
QTY
Price each
Part Numbers
Descriptions
1
$20.00
99-FS-750-4909-L&R
Black Left Side Puck
1
$20.00
99-FS-750-4900-L&R
White Left Side Puck
1
$30.00
99-FS-850-4900-L&R
Polished Billet Left Side Puck
1
$30.00
99-OF-750-4900-L
Left Side Offset Black Anodized
1
$2.00
99-HB-SH10150045
Socket Cap 10 X 1.5 X 45 (Holds puck to offset)
1
$3.50
99-HB-SH10125070
Socket Cap 10 X 1.25 X 70 Main Engine Stud
Replacement Parts List: Right Side Components (as if you were sitting on the bike)
1
$20.00
99-FS-750-4909-L&R
Black Right Side Puck
1
$20.00
99-FS-750-4900-L&R
White Right Side Puck
1
$30.00
99-FS-850-4900-L&R
Polished Billet Right Side Puck
1
$30.00
99-OF-750-4900-R
Right Side Offset Black Anodized
1
$2.00
99-HB-SH10150045
Socket Cap 10 X 1.5 X 45 (Holds puck to offset)
1
$3.50
99-HB-SH10125080
Socket Cap 10 X 1.25 X 80 Main Engine Stud
Frame Sliders: Left and right frame sliders are the same length.
Offsets: Flat offset goes on the right side.
1.
Open kit and disassemble the frame sliders from the machined offsets. Kit consists of two CNC
machined 6061-T6 aluminum offsets (brackets), two frame sliders, Two 10 X 1.5 X 45 bolts,
one 10 X 1.25 X 70 bolt and one 10 X 1.25 X 80 bolt
2.
Remove the bodywork from left and right side to expose mounting location.
3.
Make sure you keep track of what bolts came out of. Tip: (We use two separate trays to
distinguish what side the bolts came from.)
