XTnano – Version 10.04 – Operating Manual

EVS Broadcast Equipment SA – January 2011

Issue

10.04.A


9

3. Main Menu

After the boot sequence of the Multicam system, the LCD screen of the Remote

Control panel will display the Main menu:

2 Rec 2 Play

Server

Ver:10.03.xx


F1:

1 Remote

F6: Exit

F2: 2 Remote

F7: Clear all clips

F3:

F8: Stop Record

F4:

F9: Fill playlist

F5: Char. On/Off

Setup

1Pgm+Prv

2 Pgm

The Main menu has special function key operations as shown above, as well as
the “soft” keys options to enter 1Pgm+Prv, 1 Pgm, or 2 Pgm modes (if available)

and to enter the Setup menu to configure your remote controller or to add special
functions to your application.

Note

If 2 channels are available for the first Remote, the B key will display
2 Pgm.

H

OW TO

R

ETURN TO THE

M

AIN

M

ENU

From any section of the application, except Playlist mode, press SHIFT + MENU
on the first Remote Control panel to return to the Main menu.

F

UNCTION

K

EYS IN THE

M

AIN

M

ENU

Select the corresponding Function key (F_ key), and then press ENTER to validate
the selection.

Function Key

Use

F1 to F4

If desired, the Multicam system can be run using 1 or 2 EVS
Remote Panels. Depending on the number of play channels
available in the current configuration, 1- or 2- Remote modes
will be available from the Main menu.

F1: 1 Remote

One Remote Panel is used in the configuration

F2: 2 Remotes

Two Remote Panels are used in the configuration.
