32 Configuring OpenCube XFReader
Track Selection and Audio Splitting Examples
Name Description
Simultaneous active channels is set to
two.
User activates track 3. The track is
stereo, so 2 channels are activated.
Simultaneous active channels is set to
two.
User activates track 6. Tracks are
mono, so track 5 and 6 are activated
(2 channels).
Simultaneous active channels is set to
one.
User activates track 4.
Simultaneous active channels is set to
one.
User activates track 1; as the
channels are dependent, two
channels are activated.
Simultaneous active channels is set to
all. All audio tracks are activated.
