USER MANUAL OpenCube XFReader 2.6
Introduction 13
1.9.2 Ancillary Data Lines
The following array describes the line where ancillary data are present on the SDI.
Ancillary source Ancillary kind SDI line
External - SCC Closed Caption Line 12
External - MCC All Line 12
MPEG-2 User Data ATSC A/53 Line 12
MPEG-2 User Data Ancillary data Line 14
MPEG-2 User Data Timecode As defined in the previous array (See 1.9.1 -
Features/Limitations)
ST 436 All Use the line number defined in SMPTE ST
436 packet
Note
OpenCube XFReader inverts the field order automatically. You can force
the field order display. See 4.1 - Overview.
