USER MANUAL OpenCube XFReader 2.6
OpenCube XFReader User Interface 25
Part Name Description
2 CEA 608 This field shows if there are CEA608 channels available in the
ancillary source selected. CEA608 is detected in:

The CDP of a SMPTE ST 436 track
(DID=0x61/SDID=0x01);

A SCC sidecar file;

A MCC sidecar file;

ATSC A/53 in MPEG-2 video essence.
3 CEA 708 This field shows if there are CEA 708 services available in the
ancillary source selected. CEA708 is detected in:

The CDP of a SMPTE ST 436 track
(DID=0x61/SDID=0x01);

A MCC sidecar file;

ATSC A/53 in MPEG-2 video essence.
4 OP47 This field shows if there are OP47 pages available in the
SMPTE ST 436 track (DID=0x43/SDID=0x02).
OpenCube XFReader will add automatically detected pages in
this field.
5 Timecodes This field shows the timecodes available in the ancillary data.
Depending the ancillary source selected by the user, the
following timecodes are displayed:

ST 436:
o ATC VITC: Displays VITC timecode embedded in the
DID=0x60/SDID=0x60;
o ATC LTC: Displays LTC timecode embedded in the
DID=0x60/SDID=0x60;
o ST 334 Timecode: Displays the timecode embedded
in the CDP of a SMPTE ST 436 track
(DID=0x61/SDID=0x01).

MPEG-2 User data:
o ATC VITC: Displays VITC timecode embedded in the
SMPTE ST 328 of MPEG-2 video essence;
o ATC LTC: Displays LTC timecode embedded in the
SMPTE ST 328 of MPEG-2 video essence.
6 AFD This field displays the Active Format Description (AFD, ST
2016-3) available in a SMPTE ST 436 track
(DID=0x41/SDID=0x05).
7 Select
overlay
caption This radio button enables the decoding and the display of the
current caption. This applies to VGA and SDI output.
