GPSMAP ® 4000/5000 Series Owner’s Manual 89
Sonar
Creating a Waypoint on the Sonar Screen
1. From the Home screen, select Sonar.
2. Select a sonar view.
3. Select Menu > Pause Sonar.
4. Set the location of the waypoint using the intersection point of the depth line and the distance line:
• For the GPSMAP 4000 series, use the Rocker to move the intersection point.
• For the GPSMAP 5000 series, touch and drag the intersection point.
5. Select an option:
• For the GSD 22, select Create Waypoint.
• For the GSD 24/26, select New Wpt.
Sonar Screen Settings
You can define and adjust the sonar screen for all sonar views.
Setting the Zoom Level
1. From the Home screen, select Sonar.
2. Select a sonar view.
3. Select Menu > Zoom.
4. Complete an action:
• For the GSD 22, select 2x Auto Zoom or 4x Auto Zoom to zoom in on the sonar data at two or four
times magnification.
• For the GSD 22, select Manual Zoom to set the depth range of the magnified area manually. Select
View Up or View Down to set the depth of the magnified area. Select Zoom in or Zoom out to
increase or decrease the magnification of the magnified area. Select Done.
• For the GSD 24/26, select Set Zoom to set the depth range of the magnified area manually. Select View
Up or View Down to set the depth of the magnified area. Select Zoom in or Zoom out to increase or
decrease the magnification of the magnified area. Select Auto to automatically adjust the depth of the
magnified area. Select Done.
• For the GSD 22 and the GSD 24/26, select Bottom Lock to zoom in on sonar data from the bottom
depth, and select Up or Down to set the depth range of the magnified area. Select Done.
Adjusting the Gain
You can control the level of detail shown on the sonar screen. To see more detail, increase the gain. If the
screen is cluttered, decrease the gain. With the GSD 24 and GSD 26, you can set the gain for each frequency
independently.
1. From the Home screen, select Sonar.
2. Select a sonar view.
3. Select Menu > Gain.
4. If necessary, select a frequency.
5. Select an option to set the gain.
6. Select Back.
Adjusting the Range of the Depth Scale
You can adjust the range of the depth scale that appears on the right side of the screen.
1. From the Home screen, select Sonar.
2. Select a sonar view.
3. Select Menu > Range.
4. Select an option.
5. Select Done.
