Fatal1ty H87 Performance Series
3
English
I/O Panel
No. Description No. Description
1 USB 2.0 Ports (USB01) 10 Front Speaker (Lime)**
2 D-Sub Port 11 Microphone (Pink)
3 Fatal1ty Mouse Port (USB2) 12 Optical SPDIF Out Port
4 USB 2.0 Port (USB3) 13 USB 3.0 Ports (USB3_23)
5 USB 3.0 Ports (USB3_01) 14 HDMI-In Port
6 LAN RJ-45 Port* 15 HDMI-Out Port
7 Central / Bass (Orange) 16 DVI-D Port
8 Rear Speaker (Black) 17 PS/2 Keyboard Port
9 Line In (Light Blue)
1 2 4
3
5 6 8
11 12 17 13 14 15 16
7
10
9
