English – ASRock Fatal1ty Z87 Professional User Manual
Page 6
2
English
No. Description
1
Power Fan Connector (PWR_FAN1)
2
ATX 12V Power Connector (ATX12V1)
3
CPU Fan Connector (CPU_FAN1)
4
CPU Fan Connector (CPU_FAN2)
5
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
6
2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
7
ATX Power Connector (ATXPWR1)
8
USB 3.0 Header (USB3_4_5)
9
SATA3 Connectors (SATA3_A3_A4)
10 SATA3 Connectors (SATA3_A1_A2)
11 SATA3 Connectors (SATA3_0_1)
12 SATA3 Connectors (SATA3_2_3)
13 SATA3 Connectors (SATA3_4_5)
14 Power Switch (PWRBTN1)
15 Reset Switch (RSTBTN1)
16 Chassis Speaker Header (SPEAKER1)
17 System Panel Header (PANEL1)
18 Power LED Header (PLED1)
19 Chassis Fan Connector (CHA_FAN1)
20 BIOS Selection Jumper (BIOS_SEL1)
21 Clear CMOS Jumper (CLRCMOS1)
22 USB 2.0 Header (USB4_5)
23 USB 2.0 Header (USB6_7)
24 USB 3.0 Header (USB3_6_7)
25 COM Port Header (COM1)
26 SLI/XFIRE Power Connector (SLI/XFIRE_PWR1)
27 Infrared Module Header (IR1)
28 SPDIF Out Connector (SPDIF_OUT)
29 Front Panel Audio Header (HD_AUDIO1)
30 Chassis Fan Connector (CHA_FAN3)
31 Chassis Fan Connector (CHA_FAN2)
