Acnodes PC 8719 - Manual (Page 20)

RS232 (Default):
Pin# Signal Name
1 DCD# (Data Carrier Detect)
2 RXD (Received Data)
3 TXD (Transmit Data)
4 DTR (Data Terminal Ready)
5 Ground
6 DSR (Data Set Ready)
7 RTS (Request To Send)
8 CTS (Clear To Send)
9 JP1 select Setting (RI/5V/12V)
RS422 (option):
Pin# Signal Name
1 422_R-
2 422_R+
3 422_T-
4 422_T+
5 Ground
6 NC
7 NC
8 NC
9 NC
RS485 (option):
Pin# Signal Name
1 NC
2 NC
3 485-
4 485+
5 Ground
6 NC
7 NC
8 NC
9 NC
23. JP2:
(2.0mm Pitch 2x3 Pin Header),COM2 jumper setting, pin 1~6 are used to select signal out of pin 9
of COM2 port.
