Storage 4 x SATA Connector
1 x CFAST Slot (option)
Ethernet 2 x PCIe Gbe LAN by Intel 82574L
4 x USB 2.0 stack ports for external
3 x USB 2.0 box Pin header for MIO1
4 x USB 2.0 box Pin header for MIO2
1 x USB 2.0 internal for mini PCIe
USB
Serial
1 x RS232/422/485 port, DB9 connector for external (COM1)
pin 9 w/5V/12V/Ring select
1 x RS232 port, DB9 connector for external (COM2)
pin 9 w/5V/12V/Ring select
1 x RS232 header for internal (COM5)
1 x RS232 header for internal (COM6), pin 9 w/5V/12V select
I/O Card TB-522:
1 x 422/485 select header for internal MIO1 (COM3)
1 x RS232 header for internal MIO1 (COM4)
Digital I/O 8-bit digital I/O by Pin header by MIO2
4-bit digital Input
4-bit digital Output
Battery Support CR2477 Li battery by 2-pin header
Support CR2032 Li battery (option)
Audio Support Audio via Realtek ALC662 HD audio codec
Support Line-out, MIC by JACK1
Support Line-in, Line-out, MIC by 2x6-pin header
Keyboard
/Mouse
PS2 K/B and Mouse by MIO2
1 x PS/2 keyboard
1 x PS/2 mouse
Expansion Bus 1 x PCI-express x16 extend by 4x30 pin socket
2 x PCI-express x1 extend by 4x10 pin socket
1 x mini-PCI-express slot
1 x CRT 2x5 Pin Header
Power
Management
1 x 3-pin power input connector (Wide range DC+9V~32V)
1 x ATX Power Input
（2x2Pin and 3Pin, option）
DC5V/12V output by 1x4 pin Connectors
Switches and
LED Indicators
Power on/off switch by TB-522 or TB-523
Reset switch by MIO2
Power LED status by MIO2
