RMC 7135

1U Rackmount System

Overheat

When this LED is on it indicates an overheat condition, which may be caused by cables obstructing the
airflow in the system or the ambient room temperature being too warm. Check the routing of the cables and
make sure all fans are present and operating normally. You should also check to make sure that the chassis
covers are installed. Finally, verify that the heatsinks are installed properly (see Chapter5). This LED will
remain on as long as the indicated condition exists.

NIC2

Indicates network activity on LAN2 when flashing .

NIC1

Indicates network activity on LAN1 when flashing.

HDD

Channel activity for all HDDs. This light indicates IDE or SATA drive activity when
flashing.
