1.2 Product Specification
1.2.1 KDM 7170 / 7178 / 71716 Specification
Model name KDM 7170
Number of ports 1
Dimension 449.8 x 443.4 x 44 mm / 17.7 x 17.5 x 1.7 inches
Package Dimension 605 x 560 x 202 mm / 23.8 x 22.0 x 8.0 inches
Net Weight 12.0 Kg / 26.5 lbs
Gross Weight 17.0 Kg / 37.5 lbs
Display Size 17 inches
Panel Type Active Matrix TFT LCD
Resolution Capabilities Maximum Resolution up to 1280 x 1024 (SXGA)
Pixel Pitch Supports 0.264 mm x 0.264 mm
Viewing Angle (CR>10) Right-Left view 60° ~ 70°(Typ)
Up-Down View 45° ~ 60°(Typ)
Contrast Ratio 450:1
Brightness White 250 cd/m2 (Center 1 point Typ)
Back Light Four Lamps for Back Light
Supported Colors 16.2M Colors (6-bit with FRC)
Response Time Rising Time 2 ms , Decay Time 14 ms
Operating System Dos, Windows (3.1, 9x, 2000, NT4, ME, XP, 2003 Server)
Linux, Novell 3.12-6, HP UX, SUN
Multi Platform Support PS/2, SUN and USB
System Cables VGA + PS/2 x 2 cable
Keyboard Mouse 106 key PS/2 keyboard with touch pad
Sync 45 ~ 80 KHz
Power Source 100 ~ 240 VAC input
Power Consumption 25W, 19.05W for Panel
Temperature Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity 10% ~ 90% RH
Chassis Construction Heavy duty steel materials
Keyboard Language USA, UK, German, French, Spanish, Italian, Portuguese,
Dutch, Swiss, Belgium, Swedish, Norwegian, Danish, Japan,
Taiwan, Russian, Hebrew
Certification CE / FCC, UL / CUL / C-Tick
Table 1-4. KDM 7170 Specification
