10
KDM 71XXX series User’s
Manual
2. Panel Controls and OSD Function
Controls Description
Soft power on/off button. Adjacent LED is lit when
on.
Auto
Auto-synchronize and scale down display to any
valid factory preset timings.
Up Press to scroll the function you want to adjust.
Down Press to scroll the function you want to adjust.
Menu
To access the main menu. This button also acts as
the “Enter” button.
Table 2-1. Panel Controls
Figure 2-1. KDM 717XX OSD Control Bar
Figure 2-2. KDM 719XX OSD Control Bar
2.1 Auto Tune
Press the “auto tune” button. The panel will adjust the display size
automatically and also tune the panel to its best condition.
