KDM series User’s Manual
39
Figure 2-5. Console Installation
2.3 Optional Module Installation
IP Module
Please refer to “IP KVM Module User Manual” for details.
IP Remote Console
Installation: Power off the KVM switch firstly. Remove the cover of the add-on
slot, slide in the IP Module and make sure the module is fully inserted into the
slot.
The IP Module redirects local keyboard, mouse and video data to a remote
administration console. It allows you to control one or many computers locally at
the server site or remotely via the Internet using a standard browser.
Figure 2-6. IP Module Installation
