KDM series User’s Manual
44
Example: hitting Scroll Lock twice then hitting key 1, key 0, and key 1 will
switch to bank 1 port 01. The first port is local at bottom right at the back panel.
Scroll
Lock
Scroll
Lock
1 0 1
Figure 4-1. Hotkey Example
There are two methods to activate the OSD menu.
1. Activate OSD by Mouse
Hold the left mouse button press and release the Esc key will active the Port
Display. Hold the right mouse button press and release the Esc key will active
the OSD.
2. Active OSD by press Hotkey twice then press Space bar.
