Accusys ExaSAN SWF16 User Manual
Exasan swf16, User guide

ExaSAN SWF16
User Guide
Includes hardware setup information for:
•
PCIe 2.0 switch (Model: SWF16)
•
PCIe 2.0 RAID System (Models:A12S2-PS; B08S2-PS))
•
QSFP HBA (Model: ACS-63200NT(Z1M))
•
QSFP PCIe Cables
Also includes software setup information for:
•
Switch management software: Switch Web GUI
•
SAN management software: SANit
Accusys, Inc.,
January 10, 2013
Version: V1.0
Table of contents
Document Outline
- Notice
- About This Guide
- Guide to Conventions
- Trademarks
- 1. Introducing ExaSAN PCIe2.0 switch
- 2. Preparing to Install ExaSAN SWF16
- 3. Installing the ExaSAN SWF16
- 4. Using Switch Web GUI & SANit
- 4.1 ExaSAN switch web GUI
- 4.2 Creating arrays by SWF16 – “Quick Setup”
- 4.3 Log download – “Event Management”
- 4.4 System Management
- 4.5 Environment status monitoring
- 4.6 SANit FS configuration
- 5. RAID Overview
- 6. Appendices
