25
JBOD System
Quick Start Guide
4.Connect the host server to the LAN switch.
This connection can be configured using GUI (Graphical User Interface)
or CLI (Command Line Interface).
• To configure using GUI
The JBOD system can be detected automatically by the GUI when
connected. The chassis ID corresponds to the enclosure tab number
shown in the GUI. The number of enclosure tabs may vary according to
the number of connected JBOD systems. The connection in Figure 1-3 will
show three JBOD enclosure tabs. The enclosure display may show empty
slots depending on the number of drives installed. The following table
shows the supported number of JBOD systems and hard disks.
* When there are 5 JBOD enclosures, the last JBOD can only contain 8 disks.
* When there are 3 JBOD enclosures, the last JBOD can only contain 16 disks.
1.Connect and login to the GUI webpage.
• Login name = admin
• Password = 0000
2.Check if the status of all the hard disks are unused.
3.Create disk groups.
4.Create logical disks.
5.Create LUN mapping.
A12R-SJ
JBOD System
Memory size Units of HDD
Number of JBOD
Enclosure
12-bay
1G 64 5*
2G or higher 120 9
A16R-SJ
JBOD System
Memory size Units of HDD
Number of JBOD
Enclosure
16-bay
1G 64 3
2G or higher 120 7
A24R-SJ
JBOD System
Memory size Units of HDD
Number of JBOD
Enclosure
24-bay
1G 64 3*
2G or higher 120 4
