JBOD System
Quick Start Guide
20
To establish the connection:
1.Connect the RAID system EXP port to the CH1 port of the JBOD1 using a
SAS cable.
2.To connect to the next JBOD, connect the EXP port of JBOD1 to the
CH1 port of JBOD2.
3.Follow the same procedures to connect the succeeding JBOD
enclosures.
4.To make a loop, connect the EXP port of JBOD3 to the CH1 port of
JBOD2.
5.Connect the EXP port of JBOD2 to the CH1 port of JBOD1.
6.Connect the EXP port of the RAID system to the CH1 port of JBOD3.
7.Set the chassis ID:
• A16R-FS (RAID) = 0
• A16R-SJ (JBOD1) = 1
• A16R-SJ (JBOD2) = 2
• A16R-SJ (JBOD3) = 3; and so forth for more JBOD enclosures
Note
For more information, see 2.3 SAS JBOD Enclosure Display on the
Accusys RAID GUI user’s manual.
To configure, see .
