19
SETTING THE OPERATING MODE
“MODE” button
Pressing the “MODE” button causes the
operating mode to change. The “MODE”
button must be released and then pressed
again to switch to the next mode. The active
mode will always be displayed in normal
operation.
MODE FAN
NOTE
• If the “MODE” button is not pressed for
15 seconds, the next command
always changes the mode to OFF.
The available operating modes to select
from are:
OFF Mode
• OFF mode
• Ambient Temperature: if configured by
canceling the ambient environment
sensor. Otherwise none.
Available Buttons
• “MODE” button
Remote Cooling Only
OFF (disconnected)
COOL (Cooling)
DRY (dehumidification)
FAN ONLY (ventilation)
COOL and DRY modes
• ICON of the Operating Mode.
• Ambient Temperature: if configured by
canceling the temperature sensor of the
ambient environment unit (operated by
the environment controller); otherwise
the temperature is selected by the user
with the “SET TEMP” icon.
• FAN/LOUVRE icon with the Fan and
Louver settings – air deflector – selected
by the user.
Available Buttons
• All the Buttons are available.
DRY
Dehumidification Operation
COOL
Cooling Operation
