HONDA 2011 Odyssey - Manual (Page 637)

Remove the socket from the light
assembly by turning it one-quarter
turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Place a cloth on the edge of the
lens segment to prevent scratches.
Remove each lens segment by
carefully prying on its edge with a
small flat-tip screwdriver.
Remove the screws with a Phillips-
head screwdriver, then remove
the light assembly from the
tailgate.
Insert the socket back into the
light assembly. Turn it clockwise
to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Reinstall the cover.
1.
2.
3.
4.
5.
6.
7.
Lights
Replacing a High-mount Brake
Light Bulb
634
SCREWS
LENS SEGMENTS
SOCKET
BULB
10/07/17 10:59:13 31TK8600_639
2011 Odyssey
