FIAT Sedici User Manual

Page 218

background image

217

20A

15A

15A

15A

–

–

–

–

–

–

–

–

–

–

Air compressor fuse

Throttle motor fuse

Automatic transaxle fuse (for versions/markets, where provided)

Fuel injection fuse

Automatic transaxle relay (for versions/markets, where provided)

Air compressor relay

Fuel pump relay

Condenser fan relay

Front fog light relay

Throttle motor relay

FI MAIN

Starting motor relay

Radiator fan relay

Shift lock relay

Main fuse / Primary fuse

(16)

(17)

(18)

(19)

(20)

(21)

(22)

(23)

(24)

(25)

(26)

(27)

(28)

(29)
