FIAT Panda - Manual (Page 171)

TOWING THE CAR
The tow hook, which is supplied with the car, is
housed in the tool box, under the carpet in the
luggage compartment.
ATTACHING THE TOW HOOK
Manually remove cap A fig. 138 (front bumper) or A
fig. 139 (rear bumper) pressing the lower part,
take the tow hook B fig. 138 fig. 139 from its housing
in the tool box and tighten it completely on the
front or rear threaded pin.
WARNING
Before towing, turn the ignition key to
MAR and then to STOP without
removing it.The steering column will
automatically lock when the key is removed and
the wheels cannot be steered.
WARNING
Before tightening the hook clean the
threaded housing thoroughly. Make sure
that the hook is fully fastened in the housing
before towing the car.
fig. 138 F0W0021 fig. 139 F0W0022
