Note: Cams should
be tightened in a
clockwise motion
Step 9: Add Base Assembly to Bottom
Flip and align the assembled base frame so the holes in the assembled base frame line up with the Dowels (c) and Cam Pins (b) on the
Bottom (p). Proceed to tighten all 6 of the Cams (a) on the Front Base Rails (w) that correspond with the Cam Pins on the Bottom so that
the assembled base frame is secured to the Bottom.
Diagram 9
w
a
p
b
c
Step 10: Add Legs
To add the Legs (y) first slide the Rubber Spacer (g) so it fits into the Aluminum Spacer (h). Then take a M6 Bolt (f) and insert it through
the Outside Panel (s,t), the Spacer Assembly and finally thread it into the Leg. See the Detailed View of Diagram 10 for assistance. Re-
peat this process for the remaining holes on the left and right leg. Tighten each M6 Bolt with the Allen Key (n) until tight.
Detailed View
y
g
h
Diagram 10
s
f
