Attaching and Adjusting the Fixed Support Bracket
95
Figure 10
shows an VCX 2102 Telephone in the wall-mount position.
Safe wall mounting requires 3/4-inch drywall and 1.5-inch drywall screws.
Figure 10 Wall-Mount Position
1 Handset support peg
2 Wall with a solid backing
3 Support bracket in the low-profile position on opposite end of telephone
Security Wall-Mount
Bracket
Every VCX telephone can be fitted with an optional security wall-mount
bracket that ensures that the device cannot be removed by unauthorized
persons. For how to order this bracket, consult your 3Com VCX
Voice-Authorized Partner. Read and follow the instructions that come
with the bracket.
1
2
3
