Fan Status
At the bottom of all screens is an image of the Switch’s front
panel, as shown in
. At the right hand side of the panel
under the 3Com company name is an image depicting two fans.
These represent the Switch’s fans and their current status. A
green fan indicates normal operation, a red fan indicates that the
fan has failed to start. In the event of fan failure refer to
“Technical Support” on page 52.
Figure 6 Switch front panel layout
Summary Screen
Figure 7 Summary Screen
Fan failure
Fan operating
