PCI v3.0.151 Getting Started Guide www.xilinx.com 9
UG157 August 31, 2005
Conventions R
Online Document
The following conventions are used in this document:
Italic font
Variables in a syntax
statement for which you must
supply values
ngdbuild design_name
References to other manuals
See the Development
System Reference Guide
for more information.
Emphasis in text
If a wire is drawn so that it
overlaps the pin of a symbol,
the two nets are not
connected.
Square brackets [ ]
An optional entry or
parameter. However, in bus
specifications, such as
bus[7:0]
, they are required.
ngdbuild [option_name]
design_name
Braces { }
A list of items from which you
must choose one or more
lowpwr ={on|off}
Vertical bar |
Separates items in a list of
choices
lowpwr ={on|off}
Vertical ellipsis
.
.
. Repetitive material that has
been omitted
IOB #1: Name = QOUT’
IOB #2: Name = CLKIN’
.
.
.
Horizontal ellipsis . . . Omitted repetitive material
allow block block_name
loc1 loc2 ... locn;
Convention Meaning or Use Example
Convention Meaning or Use Example
Blue text
Cross-reference link to a
location in the current
document
See “Additional Resources”
for details.
See “Title Formats” in Chapter
1 for details.
Blue, underlined text Hyperlink to a website (URL)
Go to http://www.xilinx.com
for the latest speed files.
