York 251934-YTG-J-0910 User Manual
Page 68
251934-YTG-J-0910
68
Johnson Controls Unitary Products
Electric Heat Minimum Supply Air
Size
(Tons)
Voltage
Minimum Supply Air (CFM)
Heater kW
18
36
54
72
180
(15)
208/230-3-60
4500
4500
5000
5000
460-3-60
4500
4500
5000
4500
600-3-60
4500
4500
4500
4500
210
(17.5)
208/230-3-60
6000
6000
6000
6000
460-3-60
6000
6000
6000
6000
600-3-60
6000
6000
6000
6000
240
(20)
208/230-3-60
6000
6000
6000
6000
460-3-60
6000
6000
6000
6000
600-3-60
6000
6000
6000
6000
300
(25)
208/230-3-60
7500
7500
7500
7500
460-3-60
7500
7500
7500
7500
600-3-60
7500
7500
7500
7500
For units with VFD and electric heat, the speed of the
indoor blower motor continues to be controlled by duct
static pressure via the VAV control board.
If there are VAV boxes present in the duct system,
the boxes must be driven to the full-open position
using a customer-supplied power source to assure
adequate airflow across electric heating elements
or gas heat exchanger tubes.
Indoor Blower Specifications
Size
(Tons)
Model
Motor
Motor Sheave
Blower Sheave
Belt
HP
RPM
Eff.
SF
Frame
Datum Dia.
(in.)
Bore (in.)
Model
Datum Dia.
(in.)
Bore (in.)
Model
180
(15)
ZJ/ZF
5
1725
0.89
1.15
184T
5.2 - 6.4
1 1/8
1VP65
10.4
1
BK110
BX85
5
1725
0.89
1.15
184T
5.2 - 6.4
1 1/8
1VP65
8.4
1
BK090
BX81
210
(17.5)
ZJ/ZF
5
1725
0.89
1.15
184T
4.2 - 5.5
1 1/8
1VP60
10.4
1 3/16
BK110
BX78
7.5
1725
0.91
1.15
213T
4.2 - 5.5
1 3/8
1VP60
8.4
1 3/16
BK090
BX75
240
(20)
ZJ/ZF
5
1725
0.89
1.15
184T
4.2 - 5.5
1 1/8
1VP60
10.4
1 3/16
BK110
BX78
7.5
1725
0.91
1.15
213T
4.2 - 5.5
1 3/8
1VP60
8.4
1 3/16
BK090
BX75
300
(25)
ZJ/ZF
7.5
1725
0.91
1.15
213T
4.2 - 5.5
1 3/8
1VP60
9.5
1 7/16
1B5V94
BX78
10
1725
0.89
1.15
215T
5.8 - 7.0
1 3/8
1VP75X
11.1
1 7/16
1B5V110 5VX840
15
1725
0.91
1.15
254T
6.2 - 7.4
1 5/8
1VP75X
9.5
1 7/16
1B5V94
5VX860
180
(15)
ZR
5
1725
0.89
1.15
184T
5.2 - 6.4
1 1/8
1VP65
10.4
1
BK110
BX85
7.5
1725
0.91
1.15
213T
5.2 - 6.4
1 3/8
1VP65
8.4
1
BK090
BX81
240
(20)
ZR
7.5
1725
0.91
1.15
213T
4.2 - 5.5
1 3/8
1VP60
10.4
1 3/16
BK110
BX78
10
1725
0.89
1.15
215T
4.2 - 5.5
1 3/8
1VP60
8.4
1 3/16
BK090
BX75
300
(25)
ZR
7.5
1725
0.91
1.15
213T
4.2 - 5.5
1 3/8
1VP60
9.5
1 7/16
1B5V94
BX78
10
1725
0.89
1.15
215T
5.8 - 7.0
1 3/8
1VP75X
11.1
1 7/16
1B5V110
5V840
15
1725
0.91
1.15
254T
6.2 - 7.4
1 5/8
1VP75X
9.5
1 7/16
1B5V94
5VX860
Power Exhaust Specifications
Voltage
Motor
Motor
CFM @
0.2 ESP
HP
RPM
1
1. Motors are multi-tapped and factory wired for high speed.
QTY
LRA
FLA
MCA
208/230-1-60
3/4
1075
1
7.7
5.0
6.25
5250
460-1-60
3/4
1075
1
4.1
2.2
2.75
5250
575-1-60
3/4
1050
1
2.84
1.5
1.875
5250
