Page 58
Chapter 4 Connection Wizard
ZyXEL NBG-334SH User’s Guide
58
Figure 28 Wizard Step 2: Wireless LAN
The following table describes the labels in this screen.
"
The wireless stations and ZyXEL Device must use the same SSID, channel ID
and WEP encryption key (if WEP is enabled), WPA-PSK (if WPA-PSK is
enabled) or WPA2-PSK (if WPA2-PSK is enabled) for wireless
communication.
Table 9 Wizard Step 2: Wireless LAN
LABEL
DESCRIPTION
Name (SSID)
Enter a descriptive name (up to 32 printable 7-bit ASCII characters) for the wireless
LAN.
If you change this field on the ZyXEL Device, make sure all wireless stations use the
same SSID in order to access the network.
Security
Select a Security level from the drop-down list box.
Choose Auto to have the ZyXEL Device generate a pre-shared key automatically. A
screen pops up displaying the generated pre-shared key after you click Next. Click
OK to continue.
Choose None to have no wireless LAN security configured. If you do not enable any
wireless security on your ZyXEL Device, your network is accessible to any wireless
networking device that is within range. If you choose this option, skip directly to
.
Choose Basic (WEP) security if you want to configure WEP Encryption parameters. If
you choose this option, go directly to
Choose Extend (WPA-PSK or WPA2-PSK) security to configure a Pre-Shared Key.
Choose this option only if your wireless clients support WPA-PSK or WPA2-PSK
respectively. If you choose this option, skip directly to
Channel
Selection
The range of radio frequencies used by IEEE 802.11b/g wireless devices is called a
channel.
Select a channel that is not used by any nearby devices.
Back
Click Back to display the previous screen.
Next
Click Next to proceed to the next screen.
Exit
Click Exit to close the wizard screen without saving.
