A-6000 High Speed, Long Range Ethernet Wireless Bridge
Hardware Installation 2-5
10. CAT-5 Straight-through Ethernet cable
The CAT-5 STP cable is 2m in length. This cable is used to connect the network/power injector and the CPE.
The picture of this cable is shown below.
Figure 2-12 Ethernet Cable
11. Switching Power Adapter
The switching power adapter is to supply the power for the outdoor unit. The input to this adapter is
100~240VAC and the output is 15VDC. The picture is shown below.
Figure 2-13 Switching Power Adaptor
2.2 Hardware Installation
1. A-6000 Physical Connection
The physical cable connection of the A-6000 is shown in the following pictures.
