Lubrication
CAUTION! No lubricating agents of any kind should be used on this
printer! Some commercially available lubricants will damage the finish
and the mechanical parts, if used.
Zebra Z4M Printer User’s Guide
61
Upper
cutter
blade
Lower
cutter
blade
Cutter
motor
thumbnut
Figure 26
