COOLING CAPACITIES (m
3
/s Air Flow) - 180 UNITS
Air On
Evaporator Coil
Total
Cap. 1
kW
Power
Input 2
kW
Sensible Capacity 1 , kW
Entering Dry Bulb Temp., ° C
m
3
/s WB ° C 32 30 28 26 24 22
@27
°
C Air Temperature on Condenser Coil
3.40
23 66.4 14.7 51 44 37 30 23 -
21 62.3 14.4 59 52 44 37 30 23
19 58.2 14.0 58 58 52 45 38 31
17 56.7 14.0 57 57 56 49 41 34
15 55.2 13.9 55 55 55 52 45 37
2.80
23 61.5 14.5 46 40 34 27 21 -
21 57.7 14.2 53 46 40 34 28 22
19 53.9 13.9 54 53 47 41 35 28
17 52.5 13.8 52 52 51 44 38 32
15 51.1 13.7 51 51 51 48 42 35
2.10
23 57.1 14.3 37 32 28 23 19 -
21 53.6 14.0 43 38 33 29 24 19
19 50.1 13.6 48 44 39 34 30 25
17 48.7 13.6 49 47 42 37 33 28
15 47.4 13.5 47 47 45 40 36 31
@35
°
C Air Temperature on Condenser Coil
3.40
23 60.7 15.9 50 43 36 29 22 -
21 57.2 15.5 57 50 43 36 29 22
19 53.7 15.2 54 54 51 43 36 29
17 52.3 15.1 52 52 52 47 40 32
15 51.0 15.0 51 51 51 47 40 33
2.80
23 56.3 15.9 44 38 32 25 19 -
21 53.1 15.6 51 44 38 32 26 20
19 49.8 15.2 50 50 45 39 32 26
17 48.6 15.1 49 49 48 41 35 29
15 47.3 15.0 47 47 47 44 38 32
2.10
23 51.9 15.6 36 31 27 22 17 -
21 48.9 15.3 41 37 32 27 23 18
19 45.9 14.9 46 42 38 33 28 24
17 44.7 14.8 45 45 40 35 31 26
15 43.6 14.7 44 44 43 38 33 29
@46
°
C Air Temperature on Condenser Coil
3.40
23 49.6 18.2 46 39 32 25 18 -
21 47.3 17.6 47 46 39 32 25 18
19 45.0 17.1 45 45 45 39 32 25
17 43.6 17.1 44 44 44 40 33 26
15 42.1 17.1 42 42 42 39 31 24
2.80
23 49.4 17.8 41 35 29 23 17 -
21 47.2 17.2 47 42 36 29 23 17
19 44.9 16.6 45 45 42 36 30 24
17 43.4 16.6 43 43 43 37 31 25
15 42.0 16.6 42 42 42 39 33 27
2.10
23 46.5 17.5 33 29 24 19 15 -
21 44.4 17.0 39 34 30 25 20 16
19 42.3 16.4 42 40 35 31 26 21
17 40.9 16.4 41 41 36 32 27 22
15 39.5 16.4 40 40 38 33 28 24
1 These capacities are gross ratings. For net capacity, deduct the heat of the supply air blower motor. Refer to the appropriate Blower Performance Table for the kW of the
supply air blower motor.
2 These ratings include the condenser fan motors (Total 2.3 kW) and the compressor motors but not the supply air blower motor.
