York PREDATOR BP 090 - Manual (Page 9)

259336-YTG-B-0606
Unitary Products Group 9
TABLE 3: COOLING CAPACITY 7-1/2 TON HP COOL IMPERIAL
Air On
Evap. Coil
Temperature of Air on Condenser Coil 85°F Temperature of Air on Condenser Coil 95°F
CFM
WB
(°F)
Tot.
Cap. *
(MBH)
Tot.
Input †
(kW)
Sensible Capacity (MBH) *
Return Dry Bulb (°F)
Tot.
Cap. *
(MBH)
Tot.
Input †
(kW)
Sensible Capacity (MBH) *
Return Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
2250
72 109 8.7 61 55 48 42 35 #N/A #N/A 104 9.4 58 52 45 39 33 #N/A #N/A
67 98 8.4 74 68 62 55 49 42 36 92 8.9 72 66 59 53 46 40 34
62 89 8.0 88 81 75 69 62 56 49 83 8.6 83 79 73 66 60 53 47
57 95 8.0 93 87 80 74 68 61 55 84 8.5 84 82 75 69 62 56 50
2625
72 112 8.8 67 59 52 44 36 #N/A #N/A 106 9.5 64 56 49 41 34 #N/A #N/A
67 101 8.5 81 74 66 58 51 43 36 94 9.0 79 71 64 56 49 41 33
62 92 8.1 91 88 80 73 65 58 50 85 8.7 85 83 78 70 63 55 48
57 97 8.1 97 93 86 79 71 63 56 86 8.6 86 85 81 73 66 58 51
3000
72 115 8.9 73 64 55 46 38 #N/A #N/A 109 9.6 70 61 52 43 35 #N/A #N/A
67 104 8.5 88 79 70 62 53 44 35 97 9.1 86 77 68 59 51 42 33
62 94 8.2 94 94 86 77 68 59 51 88 8.8 88 88 83 75 66 57 48
57 100 8.1 100 100 92 83 75 66 57 88 8.7 88 88 86 78 69 60 51
3375
72 117 8.9 78 68 58 48 38 #N/A #N/A 112 9.7 75 65 55 45 35 #N/A #N/A
67 106 8.6 94 84 74 64 54 44 34 99 9.2 92 82 72 62 52 42 32
62 96 8.2 96 96 90 80 70 60 50 90 8.9 90 90 88 78 68 58 48
57 102 8.2 102 102 97 87 77 67 57 91 8.8 91 91 90 80 70 60 50
3750
72 120 9.0 83 72 61 50 38 #N/A #N/A 115 9.8 80 69 58 47 35 #N/A #N/A
67 108 8.6 100 89 78 66 55 44 33 102 9.3 98 87 76 64 53 42 31
62 98 8.3 98 98 94 83 72 61 50 92 8.9 92 92 92 81 70 59 48
57 104 8.2 104 104 101 90 79 68 57 93 8.9 93 93 93 82 71 60 49
Temperature of Air on Condenser Coil 105°F Temperature of Air on Condenser Coil 115°F
2250
72 101 10.1 60 53 47 40 34 #N/A #N/A 98 10.9 61 55 48 42 35 #N/A #N/A
67 88 9.6 74 67 61 54 48 42 35 84 10.3 75 69 62 56 50 43 37
62 79 9.2 79 77 74 67 61 54 48 74 9.9 74 74 74 68 62 55 49
57 79 9.2 79 78 75 68 62 55 49 74 9.9 74 74 74 68 61 55 48
2625
72 102 10.2 64 56 48 41 33 #N/A #N/A 99 10.9 63 56 48 41 33 #N/A #N/A
67 89 9.7 78 71 63 56 48 40 33 84 10.3 78 70 63 55 47 40 32
62 80 9.3 80 79 76 69 61 54 46 75 9.9 75 75 75 67 59 52 44
57 80 9.2 80 80 77 70 62 55 47 74 9.9 74 74 74 67 59 51 44
3000
72 104 10.2 68 59 50 41 33 #N/A #N/A 99 10.9 66 57 48 39 31 #N/A #N/A
67 90 9.7 83 74 65 57 48 39 30 84 10.3 80 71 63 54 45 36 28
62 81 9.3 81 81 79 70 62 53 44 75 9.9 75 75 75 66 57 49 40
57 81 9.3 81 81 80 72 63 54 45 74 9.9 74 74 74 66 57 48 39
3375
72 106 10.3 73 63 53 43 33 #N/A #N/A 100 11.0 72 62 52 42 32 #N/A #N/A
67 92 9.8 88 79 69 59 49 39 30 85 10.4 83 77 67 57 47 37 27
62 83 9.4 83 83 82 72 62 52 42 76 10.0 76 76 76 66 56 46 36
57 83 9.4 83 83 83 73 63 53 43 75 9.9 75 75 75 65 55 45 35
3750
72 108 10.4 79 68 56 45 34 #N/A #N/A 102 11.0 77 66 55 44 33 #N/A #N/A
67 94 9.9 92 85 73 62 51 40 29 86 10.5 86 82 71 60 49 38 27
62 85 9.5 85 85 85 73 62 51 40 77 10.0 77 77 77 66 54 43 32
57 85 9.4 85 85 85 74 62 51 40 76 10.0 76 76 76 65 54 43 32
Temperature of Air on Condenser Coil 125°F
2250
72 96 11.6 62 56 50 43 37 #N/A #N/A
67 80 11.0 77 70 64 58 51 45 38
62 70 10.5 70 70 70 69 62 56 50
57 69 10.5 69 69 69 67 60 54 48
2625
72 95 11.6 63 55 48 40 33 #N/A #N/A
67 79 11.0 77 70 62 54 47 39 32
62 69 10.5 69 69 69 65 58 50 43
57 68 10.5 68 68 68 63 56 48 40
3000
72 94 11.5 64 55 46 38 29 #N/A #N/A
67 78 11.0 77 69 60 51 42 34 25
62 68 10.5 68 68 68 62 53 44 35
57 67 10.4 67 67 67 60 51 42 33
3375
72 95 11.6 70 60 50 40 30 #N/A #N/A
67 78 11.0 78 74 64 55 45 35 25
62 69 10.5 69 69 69 60 50 40 30
57 68 10.5 68 68 68 58 48 38 28
3750
72 95 11.6 76 65 54 42 31 #N/A #N/A
67 79 11.1 79 79 69 58 47 36 24
62 69 10.6 69 69 69 58 47 35 24
57 68 10.5 68 68 68 57 46 34 23
* These capacities are gross ratings. For net
capacity, deduct air blower motor, MBH = 3.415
x kW. Refer to the appropriate Blower Perfor-
mance Table for the kW of the supply air
blower motor.
† These ratings include condenser fan motors
and the compressor motors but not the supply
air blower motor.
