259336-YTG-B-0606
26 Unitary Products Group
NOTE: A one-inch clearance must be provided
between any combustible material and the
supply ductwork for a distance of 3 feet from
the unit.
TABLE 37: 6 POINT LOAD WEIGHT
MODEL
LOCATION LBS. (KG)
A B C D E F
BP090
166
(75)
149
(68)
134
(61)
196
(89)
217
(98)
242
(110)
BP120
181
(82)
163
(80)
147
(67)
214
(97)
237
(108)
264
(120)
TABLE 38: UNIT WEIGHTS
MODEL
SHIPPING WEIGHT
LB. (kg)
OPERATING WEIGHT
LB. (kg)
BP090 1108 (503) 1103 (500)
BP120 1212 (550) 1207 (547)
Econ. 85 (39) 84 (38)
w/ PE 150 (68) 148 (67)
Elec. Heat *
* 54kW heater.
49 (22) 49 (22)
FIGURE 5 - UNIT DIMENSIONS
F o r B a s e r a i l
D i m e n s i o n s
S e e D e t a i l A
8 9
( 2 2 6 0 )
2 7
( 6 8 5 )
5 9
( 1 5 0 0 )
5 0 - 3 / 4
( 1 2 9 0 )
4 - 1 / 4
( 1 1 0 )
1 7 - 3 / 1 6
( 4 3 5 )
2 4 - 3 / 1 6
( 6 1 5 )
3 0 - 3 / 1 6
( 7 6 5 )
P o w e r
E n t r y
Ø 2 - 1 / 2
( 6 5 )
3 0 - 1 1 / 3 2
( 7 7 0 )
C o n t r o l
E n t r y
Ø 7 / 8
( 2 2 )
P o w e r
E n t r y
Ø 2 - 1 / 2
( 6 5 )
L E F T
F R O N T
6 - 3 / 1 6
( 1 5 5 )
C o n v e n i e n c e
P o w e r
O u t l e t
E n t r y
Ø 7 / 8
( 2 2 )
N O T E : ( x x x ) i n d i c a t e s d i m e n s i o n s
g i v e n i n m i l l i m e t e r s
F o r D r a i n
D i m e n s i o n s
S e e D e t a i l B
TABLE 39: UNIT CLEARANCES
*
* In inches and millimeters, in.(mm).
Top †
† Units must be installed outdoors. Overhanging structure or
shrubs should not obstruct condenser air discharge outlet.
72 (1830) Right 12 (305)
Front 36 (915) Left 36 (915)
Rear
‡
‡ To remove the slide-out drain pan, a rear clearance of 60”
(1525 mm) is required. If space is unavailable, the drain pan
can be removed through the front by separating the corner
wall.
36 (915) Bottom
**
** Units may be installed on combustible floors.
0 (0)
3 - 3 / 4
( 9 5 )
3 - 9 / 1 6
( 9 0 )
2 - 3 / 8
( 6 0 )
DETAIL A
5 - 3 / 8
( 1 3 5 )
DETAIL B
